Customized Machinery

High Speed Fully Auto Cling Film Shrink Packaging Machine

PPD-CFSP590

High speed fully auto cling film shrink packaging machine adopts imported electrical components,high speed automatic packaging of cling film roll,aluminium foil roll, food, medicines, beverages, bowl noodles, milk tea, mosquito coils, wallpaper, exercise books, filters, electrical switches, garbage bags, various stationery, industrial parts, and daily cosmetics body-wrap packaging.


Features:
1.Single or any packaging.
2. Color touch screen control system, the operation is extremely simple and beautiful appearance; PLC control makes the system more stable, reliable, low failure rate; bag length, speed and temperature can be adjusted separately, easy and accurate operation.
3. High-efficiency dual-temperature zone of heat shrinking furnace, high-efficiency hot air circulation, automatic temperature control to ensure the quality of shrinkage.
4.High-sensitivity photoelectric eye color mark tracking, mathematically input the sealing and cutting position to make the sealing and cutting position more accurate.
5.Temperature independent PID control, better suitable for various coating materials.

Main technical data:

Name:High Speed Fully Auto Cling Film Shrink Packaging Machine

Model:PPD-CFSP590

Max film width Max Flim size ≤590mm

Packing size : L: 60mm-320mm,W: 10mm-200mm, H: 5mm-35mm

Packing speed:30-150 (bag/min)

Film type Flim type POF and other heat shrinkable film

Power consumption packaging machine: 4.5KW; shrinking furnace: 15.5KW

Power supply: host: 220V, 50HZ/60HZ; shrink machine: 380V, 50HZ/60HZ

Machine dimensions:5000x1170x1500mm(LxWxH)

Shrinking  machine:2600x600x1700mm(LxWxH)

Weight : Host: 1000KG Shrinking machine: 600KG

NOTE:Different sizes can be customized.
