Stretch Film Slitter Rewinder Machine

Semi Auto Coreless Stretch Film Rewinder

PPD-CSFR500

Semi auto coreless stretch film rewinder is specailly designed for rewinding LLDPE stretch film jumbo roll into coreless stretch roll for hand stretch roll or corelss stretch cling film as sub roll by use the pneumatic air shaft.
It is a multi-functional model to be standard cored stretch film or cling film slitting and rewinding when use the standard rewind shafts.

Features
1. Machine is controlled by PLC system and manaul panel together.
2. Machine is semi automatic machine to take a master roll of film and rewind it in to shorter length hand or machine rolls with out a core which can save the cost a lot.
3.All color of our machine are used spraying plastic way, it can use longer and keep good appearance.

Main Data：

Name:Semi Auto Coreless Stretch Film Rewinder

Model:PPD-CSFR500

Width (mother roll):500mm

Width (finished roll):50-500mm

Mother roll OD:350mm(Max)

Inner diameter of core (mother roll):3''

Inner diameter of core (finished roll)：1.5/2/3inch

Design speed (m/min):max600m/min

Power (kw):4kw

Voltage:220/380/415V option

NOTE:Different sizes can be customized.
